4-Bedroom All Ensuite Duplex

Please read this page from start to finish before you make a purchase. Click "More details" below to see it all.

This product is the building plan for a cute 4-bedroom Duplex (detached house) with the following:

- 1 entrance porch

- 1 ante room

- 1 living room

- 1 dining area

- 1 family lounge (first floor)

- 4 bedrooms all en suite

- 1 kitchen

- 1 kitchen terrace

- 1 pantry

- 2 sit-outs (first floor)

- 2 visitor's toilets (one on each floor)

Dimensions of the building: 13m x 15m, See dimensions image at the top.

Check to make sure this will fit on the land plus clearance from walls.

After payment, please click Read Online on the page that pops up for instructions on how to receive the following files.

1. 3D images of the house
2. Ground Floor Plan (with full measurements)
3. First Floor Plan (with full measurements)
4. Elevation for the house (sides 1 and 2)
5. Elevation for the house (sides 3 and 4)
6. Lintel and Foundation Details
7. Roof Plan
8. Rafter Sectional Diagram
9. Septic Details
10. Window and Door Details
11. Parapet (Concrete Facia) Details

Bonus: Cost Estimate Spreadsheet (as at August 2025) included.

IMPORTANT: After payment, send an email to [email protected] and the files will be sent to you within 72 hours.

Want more building plans? Check out the my store front: https://selar.co/m/flochinyere
